ERF_InitCustomPertVels_CouettePoiseuille.H File Reference

Go to the source code of this file.

Functions
ParmParse	pp_for_pert_vels ("prob")
pp_for_pert_vels	query ("U_0", U_0)
pp_for_pert_vels	query ("V_0", V_0)
pp_for_pert_vels	query ("W_0", W_0)
pp_for_pert_vels	get ("prob_type", prob_type)
	AMREX_ALWAYS_ASSERT (prob_type==1||prob_type==10||prob_type==11||prob_type==20||prob_type==21)
pp_for_pert_vels	query ("pert_periods_u", pert_periods_u)
pp_for_pert_vels	query ("pert_periods_v", pert_periods_v)
pp_for_pert_vels	query ("pert_delta_u", pert_delta_u)
pp_for_pert_vels	query ("pert_delta_u", pert_delta_v)
pp_for_pert_vels	query ("pert_lo", pert_lo)
pp_for_pert_vels	query ("pert_hi", pert_hi)
	if (prob_type==1)

Variables
Real	U_0 = zero
Real	V_0 = zero
Real	W_0 = zero
int	prob_type
Real	pert_periods_u = amrex::Real(5.0)
Real	pert_periods_v = amrex::Real(5.0)
Real	pert_delta_u = zero
Real	pert_delta_v = zero
Real	pert_lo = Real(-1e34)
Real	pert_hi = Real( 1e34)
auto	problo = geomdata.ProbLo()
auto	probhi = geomdata.ProbHi()
Real	aval = pert_periods_u * two * PI / (probhi[1] - problo[1])
Real	bval = pert_periods_v * two * PI / (probhi[0] - problo[0])

Function Documentation

AMREX_ALWAYS_ASSERT()

AMREX_ALWAYS_ASSERT

(

prob_type

= =1||prob_type==10||prob_type==11||prob_type==20||prob_type==21

)

get()

pp_for_pert_vels get	(	"prob_type"	,
		prob_type
	)

if()

else if

(

prob_type

= = 1

)

                        {

        ParallelFor(xbx, [=] AMREX_GPU_DEVICE(int i, int j, int k) noexcept {
            const auto *const prob_hi  = geomdata.ProbHi();
            const auto *const dx       = geomdata.CellSize();
            const Real z = (k + myhalf) * dx[2];
            x_vel_pert(i, j, k) = U_0 * z / prob_hi[2];
        });

        ParallelFor(ybx, [=] AMREX_GPU_DEVICE(int i, int j, int k) noexcept {
            const auto *const prob_hi  = geomdata.ProbHi();
            const auto *const dx       = geomdata.CellSize();
            const Real z = (k + myhalf) * dx[2];
            y_vel_pert(i, j, k) = V_0 * z / prob_hi[2];
        });

        ParallelFor(zbx, [=] AMREX_GPU_DEVICE(int i, int j, int k) noexcept {
            z_vel_pert(i, j, k) = W_0;
        });

    // Poiseuille flow
    } else if (prob_type == 10 || prob_type == 11) {

Here is the call graph for this function:

pp_for_pert_vels()

ParmParse pp_for_pert_vels

(

"prob"

)

query() [1/9]

pp_for_pert_vels query	(	"pert_delta_u"	,
		pert_delta_u
	)

query() [2/9]

pp_for_pert_vels query	(	"pert_delta_u"	,
		pert_delta_v
	)

query() [3/9]

pp_for_pert_vels query	(	"pert_hi"	,
		pert_hi
	)

query() [4/9]

pp_for_pert_vels query	(	"pert_lo"	,
		pert_lo
	)

query() [5/9]

pp_for_pert_vels query	(	"pert_periods_u"	,
		pert_periods_u
	)

query() [6/9]

pp_for_pert_vels query	(	"pert_periods_v"	,
		pert_periods_v
	)

query() [7/9]

pp_for_pert_vels query	(	"U_0"	,
		U_0
	)

query() [8/9]

pp_for_pert_vels query	(	"V_0"	,
		V_0
	)

query() [9/9]

pp_for_pert_vels query	(	"W_0"	,
		W_0
	)

Variable Documentation

aval

Real aval = pert_periods_u * two * PI / (probhi[1] - problo[1])

bval

Real bval = pert_periods_v * two * PI / (probhi[0] - problo[0])

pert_delta_u

Real pert_delta_u = zero

pert_delta_v

Real pert_delta_v = zero

pert_hi

Real pert_hi = Real( 1e34)

pert_lo

Real pert_lo = Real(-1e34)

pert_periods_u

Real pert_periods_u = amrex::Real(5.0)

pert_periods_v

Real pert_periods_v = amrex::Real(5.0)

prob_type

int prob_type

probhi

auto probhi = geomdata.ProbHi()

problo

auto problo = geomdata.ProbLo()

U_0

Real U_0 = zero

Referenced by if().

V_0

Real V_0 = zero

Referenced by if().

W_0

Real W_0 = zero

Referenced by if().
