#include <DataStruct.H>

Collaboration diagram for SolverChoice:

[legend]

Public Member Functions
void	init_params (int max_level)

void	display ()

void	build_coriolis_forcings ()

Public Attributes
AdvChoice	advChoice

DiffChoice	diffChoice

SpongeChoice	spongeChoice

amrex::Vector< TurbChoice >	turbChoice

std::string	pp_prefix {"erf"}

int	no_substepping = 0

int	force_stage1_single_substep = 1

int	incompressible = 0

int	constant_density = 0

int	project_every_stage = 1

int	ncorr = 1

amrex::Real	poisson_abstol = 1e-10

amrex::Real	poisson_reltol = 1e-10

bool	test_mapfactor = false

bool	use_terrain = false

int	buoyancy_type = 1

bool	use_gravity = false

bool	use_coriolis = false

bool	rayleigh_damp_U = false

bool	rayleigh_damp_V = false

bool	rayleigh_damp_W = false

bool	rayleigh_damp_T = false

bool	use_lagged_delta_rt = true

amrex::Real	gravity

amrex::Real	c_p = Cp_d

amrex::Real	rdOcp

amrex::Real	grid_stretching_ratio = 0

amrex::Real	zsurf = 0.0

amrex::Real	dz0

amrex::Real	coriolis_factor = 0.0

amrex::Real	cosphi = 0.0

amrex::Real	sinphi = 0.0

bool	custom_rhotheta_forcing = false

bool	custom_moisture_forcing = false

bool	custom_w_subsidence = false

bool	custom_geostrophic_profile = false

bool	custom_forcing_prim_vars = false

bool	use_explicit_most = false

bool	time_avg_vel = false

bool	use_NumDiff {false}

amrex::Real	NumDiffCoeff {0.}

CouplingType	coupling_type

TerrainType	terrain_type

MoistureType	moisture_type

WindFarmType	windfarm_type

LandSurfaceType	lsm_type

ABLDriverType	abl_driver_type

amrex::GpuArray< amrex::Real, AMREX_SPACEDIM >	abl_pressure_grad

amrex::GpuArray< amrex::Real, AMREX_SPACEDIM >	abl_geo_forcing

int	ave_plane {2}

bool	do_cloud {true}

bool	do_precip {true}

bool	use_moist_background {false}

amrex::Real	latitude_lo

amrex::Real	longitude_lo

Detailed Description

Container holding many of the algorithmic options and parameters

Member Function Documentation

◆ build_coriolis_forcings()

void SolverChoice::build_coriolis_forcings ( )

inline

     {
         amrex::ParmParse pp(pp_prefix);

         // Read the rotational time period (in seconds)
         amrex::Real rot_time_period = 86400.0;
         pp.query("rotational_time_period", rot_time_period);

         coriolis_factor = 2.0 * 2.0 * PI / rot_time_period;
         amrex::Print() << "Coriolis factor = " << coriolis_factor << std::endl;

         amrex::Real latitude = 90.0;
         pp.query("latitude", latitude);

         // Convert to radians
         latitude *= (PI/180.);
         sinphi = std::sin(latitude);
         cosphi = std::cos(latitude);

         if (abl_driver_type == ABLDriverType::GeostrophicWind)
         {
             // Read in the geostrophic wind -- we only use this to construct
             //     the forcing term so no need to keep it
             amrex::Vector<amrex::Real> abl_geo_wind(3);
             pp.queryarr("abl_geo_wind",abl_geo_wind);

             abl_geo_forcing = {
                 -coriolis_factor * (abl_geo_wind[1]*sinphi - abl_geo_wind[2]*cosphi),
                  coriolis_factor *  abl_geo_wind[0]*sinphi,
                 -coriolis_factor *  abl_geo_wind[0]*cosphi
             };
         }
     }

Referenced by init_params().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ display()

void SolverChoice::display ( )

inline

     {
         amrex::Print() << "SOLVER CHOICE: " << std::endl;
         amrex::Print() << "no_substepping              : " << no_substepping << std::endl;
         amrex::Print() << "force_stage1_single_substep : "  << force_stage1_single_substep << std::endl;
         amrex::Print() << "incompressible              : "  << incompressible << std::endl;
         amrex::Print() << "use_coriolis                : " << use_coriolis << std::endl;
         amrex::Print() << "use_gravity                 : " << use_gravity << std::endl;

         if (coupling_type == CouplingType::TwoWay) {
             amrex::Print() << "Using two-way coupling " << std::endl;
         } else if (coupling_type == CouplingType::OneWay) {
             amrex::Print() << "Using one-way coupling " << std::endl;
         }

         if (terrain_type == TerrainType::Static) {
             amrex::Print() << "Using static terrain " << std::endl;
         } else {
             amrex::Print() << "Using moving terrain " << std::endl;
         }

         if (abl_driver_type == ABLDriverType::None) {
             amrex::Print() << "ABL Driver Type: " << "None" << std::endl;
             amrex::Print() << "No ABL driver selected " << std::endl;
         } else if (abl_driver_type == ABLDriverType::PressureGradient) {
             amrex::Print() << "ABL Driver Type: " << "PressureGradient" << std::endl;
             amrex::Print() << "Driving abl_pressure_grad: (";
             for (int i = 0; i < AMREX_SPACEDIM; ++i)
                 amrex::Print() << abl_pressure_grad[i] << " ";
             amrex::Print() << ")" << std::endl;
         } else if (abl_driver_type == ABLDriverType::GeostrophicWind) {
             amrex::Print() << "ABL Driver Type: " << "GeostrophicWind" << std::endl;
             amrex::Print() << "Driving abl_geo_forcing: (";
             for (int i = 0; i < AMREX_SPACEDIM; ++i)
                 amrex::Print() << abl_geo_forcing[i] << " ";
             amrex::Print() << ")" << std::endl;
         }

            advChoice.display();
           diffChoice.display();
         spongeChoice.display();

         int max_level = turbChoice.size()-1;
         for (int lev = 0; lev <= max_level; lev++) {
             turbChoice[lev].display(lev);
         }
     }

Here is the call graph for this function:

◆ init_params()

void SolverChoice::init_params ( int max_level )

inline

     {
         amrex::ParmParse pp(pp_prefix);

         // Do we have terrain (or grid stretching)?
         pp.query("use_terrain", use_terrain);

         pp.query("grid_stretching_ratio", grid_stretching_ratio);
         if (grid_stretching_ratio != 0) {
             AMREX_ASSERT_WITH_MESSAGE((grid_stretching_ratio >= 1.),
                                       "The grid stretching ratio must be greater than 1");
         }
         if (grid_stretching_ratio >= 1) {
             if (!use_terrain) {
                 amrex::Print() << "Turning terrain on to enable grid stretching" << std::endl;
                 use_terrain = true;
             }
             pp.query("zsurface", zsurf);
             if (zsurf != 0.0) {
                 amrex::Print() << "Nominal zsurface height != 0, may result in unexpected behavior"
                     << std::endl;
             }
             pp.get("initial_dz", dz0);
         }

         // Do we set map scale factors to 0.5 instead of 1 for testing?
         pp.query("test_mapfactor", test_mapfactor);

         // What type of moisture model to use
         static std::string moisture_model_string = "None";
         pp.query("moisture_model", moisture_model_string);
         if (moisture_model_string == "SAM") {
             moisture_type = MoistureType::SAM;
         } else if (moisture_model_string == "Kessler") {
             moisture_type = MoistureType::Kessler;
         }else if (moisture_model_string == "Kessler_NoRain") {
             moisture_type = MoistureType::Kessler_NoRain;
         } else {
             moisture_type = MoistureType::None;
         }

         // TODO: should we set default for dry??
         // Set a different default for moist vs dry
         if (moisture_type != MoistureType::None) {
             if (moisture_type == MoistureType::Kessler_NoRain ||
                 moisture_type == MoistureType::SAM) {
                 buoyancy_type = 1; // asserted in make buoyancy
             } else {
                 buoyancy_type = 2; // uses Tprime
             }
         }

         // Which expression (1,2 or 3) to use for buoyancy
         pp.query("buoyancy_type", buoyancy_type);
         if (buoyancy_type != 1 && buoyancy_type != 2 && buoyancy_type != 3 && buoyancy_type != 4) {
             amrex::Abort("buoyancy_type must be 1, 2, 3 or 4");
         }

         // What type of land surface model to use
         static std::string lsm_model_string = "None";
         pp.query("land_surface_model", lsm_model_string);
         if (lsm_model_string == "SLM") {
             lsm_type = LandSurfaceType::SLM;
         } else if (lsm_model_string == "MM5") {
             lsm_type = LandSurfaceType::MM5;
         } else {
             lsm_type = LandSurfaceType::None;
         }

         // Is the terrain static or moving?
         static std::string terrain_type_string = "Static";
         pp.query("terrain_type",terrain_type_string);
         if (terrain_type_string == "Moving" || terrain_type_string == "moving") {
             terrain_type = TerrainType::Moving;
         } else if (terrain_type_string == "Static" || terrain_type_string == "static") {
             terrain_type = TerrainType::Static;
         } else {
             amrex::Abort("terrain_type can be either Moving/moving or Static/static");
         }

         // Use lagged_delta_rt in the fast integrator?
         pp.query("use_lagged_delta_rt", use_lagged_delta_rt);

         if (!use_lagged_delta_rt && !(terrain_type == TerrainType::Moving)) {
             amrex::Error("Can't turn off lagged_delta_rt when terrain not moving");
         }

         // These default to true but are used for unit testing
         pp.query("use_gravity", use_gravity);
         gravity = use_gravity? CONST_GRAV: 0.0;

         pp.query("c_p", c_p);
         rdOcp = R_d / c_p;


 #if defined(ERF_USE_POISSON_SOLVE)
         // Should we project the initial velocity field to make it divergence-free?
         pp.query("project_initial_velocity", project_initial_velocity);

         pp.query("incompressible", incompressible);
         pp.query("constant_density", constant_density);
         pp.query("project_every_stage", project_every_stage);
         pp.query("ncorr", ncorr);
         pp.query("poisson_abstol", poisson_abstol);
         pp.query("poisson_reltol", poisson_reltol);
 #endif

         // Turn off acoustic substepping?
         pp.query("no_substepping", no_substepping);
         pp.query("force_stage1_single_substep", force_stage1_single_substep);

 #if defined(ERF_USE_POISSON_SOLVE)
         // If this is set, it must be even
         if (incompressible != 0 && no_substepping == 0)
         {
             amrex::Abort("If you specify incompressible, you must specific no_substepping");
         }
 #endif

         // Include Coriolis forcing?
         pp.query("use_coriolis", use_coriolis);

         // Include Rayleigh damping (separate flags for each variable)
         pp.query("rayleigh_damp_U", rayleigh_damp_U);
         pp.query("rayleigh_damp_V", rayleigh_damp_V);
         pp.query("rayleigh_damp_W", rayleigh_damp_W);
         pp.query("rayleigh_damp_T", rayleigh_damp_T);

         // Flag to do explicit MOST formulation
         pp.query("use_explicit_most",use_explicit_most);

         // Which external forcings?
         static std::string abl_driver_type_string = "None";
         pp.query("abl_driver_type",abl_driver_type_string);

         if (!abl_driver_type_string.compare("PressureGradient")) {
             abl_driver_type = ABLDriverType::PressureGradient;
         } else if (!abl_driver_type_string.compare("GeostrophicWind")) {
             abl_driver_type = ABLDriverType::GeostrophicWind;
         } else if (!abl_driver_type_string.compare("None")){
             abl_driver_type = ABLDriverType::None; // No ABL driver for simulating classical fluid dynamics problems
         } else {
             amrex::Error("Don't know this abl_driver_type");
         }

         amrex::Vector<amrex::Real> abl_pressure_grad_in = {0.0, 0.0, 0.0};
         pp.queryarr("abl_pressure_grad",abl_pressure_grad_in);
         for(int i = 0; i < AMREX_SPACEDIM; ++i) abl_pressure_grad[i] = abl_pressure_grad_in[i];

         amrex::Vector<amrex::Real> abl_geo_forcing_in = {0.0, 0.0, 0.0};
         if(pp.queryarr("abl_geo_forcing",abl_geo_forcing_in)) {
             amrex::Print() << "Specified abl_geo_forcing: (";
             for (int i = 0; i < AMREX_SPACEDIM; ++i) {
                 abl_geo_forcing[i] = abl_geo_forcing_in[i];
                 amrex::Print() << abl_geo_forcing[i] << " ";
             }
             amrex::Print() << ")" << std::endl;
         }

         if (use_coriolis)
         {
             build_coriolis_forcings();
         }

         pp.query("add_custom_rhotheta_forcing", custom_rhotheta_forcing);
         pp.query("add_custom_moisture_forcing", custom_moisture_forcing);
         pp.query("add_custom_w_subsidence", custom_w_subsidence);
         pp.query("add_custom_geostrophic_profile", custom_geostrophic_profile);
         pp.query("custom_forcing_uses_primitive_vars", custom_forcing_prim_vars);

         pp.query("Ave_Plane", ave_plane);

         pp.query("mp_clouds", do_cloud);
         pp.query("mp_precip", do_precip);
         pp.query("use_moist_background", use_moist_background);

         // Use numerical diffusion?
         pp.query("use_NumDiff",use_NumDiff);
         if(use_NumDiff) {
             pp.query("NumDiffCoeff",NumDiffCoeff);
             AMREX_ASSERT_WITH_MESSAGE(( (NumDiffCoeff >= 0.) && (NumDiffCoeff <= 1.) ),
                                       "Numerical diffusion coefficient must be between 0 & 1.");
             NumDiffCoeff *= std::pow(2.0,-6);
         }

            advChoice.init_params();
           diffChoice.init_params();
         spongeChoice.init_params();

         turbChoice.resize(max_level+1);
         for (int lev = 0; lev <= max_level; lev++) {
             turbChoice[lev].init_params(lev,max_level);
         }

         // Warn for PBL models and moisture - these may not yet be compatible
         for (int lev = 0; lev <= max_level; lev++) {
             if ((moisture_type != MoistureType::None) && (turbChoice[lev].pbl_type != PBLType::None)) {
                 amrex::Warning("\n*** WARNING: Moisture may not yet be compatible with PBL models, \n    proceed with caution ***");
             }
         }

         // Which type of refinement
         static std::string coupling_type_string = "OneWay";
         pp.query("coupling_type",coupling_type_string);
         if (coupling_type_string == "TwoWay") {
             coupling_type = CouplingType::TwoWay;
         } else if (coupling_type_string == "OneWay") {
             coupling_type = CouplingType::OneWay;
         } else {
             amrex::Abort("Dont know this coupling_type");
         }

         // Which type of windfarm model
         static std::string windfarm_type_string = "Fitch";

         pp.query("windfarm_type", windfarm_type_string);
         pp.query("latitude_lo",  latitude_lo);
         pp.query("longitude_lo", longitude_lo);
         if (windfarm_type_string == "Fitch") {
             windfarm_type = WindFarmType::Fitch;
         }
         else if(windfarm_type_string == "EWP"){
             windfarm_type = WindFarmType::EWP;
         }
         else {
             amrex::Abort("Dont know this windfarm_type. Currently only Fitch and EWP models are supported.");
         }

         // Test if time averaged data is to be output
         pp.query("time_avg_vel",time_avg_vel);
     }
